The LiDAR focusing system makes focusing easier for hand-held shooting, without relying on the surface texture of the subject.
This is especially useful in low-light environments and results in exceptional focusing capabilities.
The new LiDAR Range Finder (RS) can project 43,200 ranging points, detect within a 14-meter range, [1] and has a built-in camera with an equivalent focal length of 30 mm and a wide FOV of 70°, which can handle the focusing needs of most scenarios.
Pairing with the new Focus Motor (2022) also makes autofocus on manual lenses possible after calibration, and several lens calibration profiles can be stored.
Resolution | 448 x 298 (on RS Touchscreen) |
---|---|
Field of View | Horizontal: 57.4° Vertical: 44.6° Diagonal: 70.1° |
Frame Rate | 30 fps |
Focal Length | 30mm |
Frequency | ToF Sensor: 25 Hz Machine Learning: 30 Hz |
USB | 2 x USB Type-C Female Input |
Power Source | USB |
DC Input Power | 7 to 16 VDC |
Power Consumption | 6.8 W |
