OBSBOT Talent All-in-One Multi Cam Live Streaming & Production Studio (OPB-2404-C)

Availability:In stock
Cat No.
88694
SKU
OBS-600001
OBSBOT

Order Now - Usually available to despatch in 3-5 days

Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. For urgent click and collect where products are showing in stock, please call us at 01442 292929 or email sales@proav.co.uk to check for availability.

Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. For urgent click and collect where products are showing in stock, please call us at 01442 292929 or email sales@proav.co.uk to check for availability.

£1,100.00 £916.67
- +
Apple Pay
  • Free UK Delivery

    Free UK Delivery

    On orders over £75

  • Price Match

    Price Match

    Request here

Product Information

OBSBOT Talent All-in-One Multi Cam Live Streaming & Production Studio (OPB-2404-C)

The OBSBOT Talent Multi-Cam Production & Live Streaming Studio combines an Encoder, Switcher, Monitor and Recorder in one complete professional Live-Streaming production studio device. The plethora of different connection options, compact and portable design, battery power compatibility and built-in live video effects make the Talent multi webcam an ideal solution for high-quality Live Streaming & Studio Productions.

Multi-Cam Recording

Due to the professional NDI Connection, it’s possible to connect up to three OBSBOT Tail Air AI-powered 4K cameras and recording content at the same time, allowing for a range of unique angles for a complete recording environment.

Wide Connection Compatibility

The OBSBOT Talent multi-cam live-streaming has been designed for maximum compatibility possibilities for video, with multiple interfaces available including HDMI, SD Card, USB-A and even Ethernet. For audio, it features two built-in 3.5mm slots for monitoring live audio.

Live-Streaming Possibilities

Featuring 7 video inputs, this allows the OBSBOT Talent multi-cam live-streaming to offer strong connections to securely manage video signals. These can then be output using Wi-Fi, USB Port, 4G LTE or Ethernet to a range of popular streaming platforms such as Facebook, YouTube and Twitch.

High-Quality Screen

Each OBSBOT Talent comes with a 5.44” AMOLED FHD Touchscreen to provide high-quality and precise display for easy monitoring and control during usage and can be used either in horizontal or vertical ratios to suit any production requirements.

Live Video Editing

The Talent multi-cam is designed to allow for quick video editing during a live-streaming, with a selection of useful features and options to provide professional results including Video/Graphics Imports, Instant Video Replay, Chroma Key and more.

High-Quality Video Overlays

The OBSBOT Talent also features a selection of video overlays to be used during live productions, each with their own unique purpose to create stylish results. Picture-in-Picture can be used to provide two live videos in one, whilst Integrated Scoreboards and Countdown Timers are the perfect addition for Sporting events.

Multiple Control Methods

To provide an easy-to-use experience, the Talent live-streaming camera can be controlled by multiple methods. It can be controlled directly on the Monitor itself, using the Tail Air Smart remote control (Not included) and using the OBSBOT Live app via a Smartphone, Tablet or PC device.

Control Collaboration

For Large-scale events such as educational presentations, sporting events and exhibitions, a single Talent live-streaming webcam unit can be control from multiple locations simultaneously, ideal for a large team to focus on individual requirements. This can be achieved either directly by the unit or even around the world when used alongside an Ethernet connection.

Durable Construction

Featuring an Aluminium-Alloy body, this OBSBOT Talent multi-cam live-streaming offers a strong and durable construction to survive long-term usage. It also features a unique built-in cooling fan for better heat dissipation and to keep the unit from overheating after a long period of use.

Battery Power Option

Whilst the Talent multi-cam live-streaming comes with a mains adapter as standard, it can also be powered by two NP-F Series batteries for on-the-go usage. The OBSBOT Talent webcam features power indicators to provide an accurate display of the current levels, and offer ‘Hot-Swapping’ between batteries, to prevent the stream cutting out whenever one battery runs out of power.

  • All-in-One Live-Streaming Production
  • Built-in Video Effects Processor
  • Wide Connection Compatibility
  • Thoughtful Design & Construction
  • Multiple Control Methods
  • Battery Power Options
  • 1x Talent Monitor
  • 1x Power Adapter
  • 2x Mini Stand
  • 1x Sun Hood
  • 2x Thumb Screw
Screen
Size5.44"
TypeAMOLED
Aspect Ratio16:09
Resolution1920x1080
Brightness350 nits
Colour Depth8-bit
Contrast Ratio6000:1
Colour Gamut105% NTSC
Refresh Rate60Hz
Viewing DirectionsAll (Horizontal, Vertical)
PPI405
TouchscreenCapacitive
Screen CoatingAnti-fingerprint coating
Video Input
HDMIPort: 2x HDMI 2.0 Type-A port
Typical resolution/frame rate:
4090x2160p/3840x2160p - 23.98/24/25/29.97/30/59.94/60
1920x1080p - 23.98/24/25/29.97/30/50/59.94/60
1920x1080i - 25/29.97/30
1280x720p - 23.98/24/25/29.97/30/50/59.94/60
720x576p - 50/100
720x576i - 25/50
720x480p - 59.94/60
720x480i - 29.97/30
Colour Depth: 8/10/12-bit
Colour Sampling: RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2
USBPort: 2x USB 3.0 Type-A Port, 1x USB 3.0 Type-C Port
Resolution/frame rate: Up to 1920x1080p, 60fps
Format: YUYV, MJPG, NV12
SRT StreamCodec: H.264, H.265
Resolution/frame rate: Up to 1080p, 60fps
RTMP StreamCodec: H.264, H.265
Resolution/frame rate: Up to 1080p, 60fps
NDI StreamNDI HX2 or NDI HX3
Codec: H.264, H.265
Resolution/frame rate: Up to 1080p, 60fps
VideoResolution: Up to 4K
Codec: H.264, H.265
Format: MOV/MP4
PictureFormat: JPEG/PNG/BMP
Audio Input
Mic/line in1x 3.5mm jack, 2-Channel, 48KHz, 16-bit
Audio input from HDMI port2-Channel, 48 KHz, 16-bit
Audio input from USB Port2-Channel (only Microphone supported)
Audio input from Bluetooth device2-Channel, 48KHz, 16-bit
Other Audio inputSRT, RTMP, NDI, Embedded in video files
Background Music (BGM)MP3, M4A, WAV files
Video Output
Streaming & RecordingCodec: H.264, H.265
Resolution: 1080p, 720p, 540p, 360p (only for NDI)
Frame Rate: 60/59.94/50/30/29.97/25/24/23.98/15 fps (Encoding options change along with the frame rate of the show.)
NDI HX3 Bitrate: up to 62.0Mbps, down to 1.5Mbps
Other Bitrates: up to 30.0Mbps, down to 256kpbs
Key Frame Interval: Customizable
Profile: High profile, Main Profile, Baseline Profile
Bitrate mode: VBR, CBR
USB-CPort: 1x USB 3.0 Type-C Port
Output mode: DP-OUT, UVC/UAC
Resolution: 1920x1080
Frame Rate: 60fps, 50fps
Sampling format: RGB 4:4:4
Audio Output
Streaming and Recording2-Channel, 16-bit, 48 KHz, aac, 64kbps/96kbps/128kbps
Headphone output1x 3.5mm jack, 2-channel, 48 KHz, 16-bit
Audio Output via Bluetooth device2-channel, 48 KHz, 16-bit
Audio Output via USB-C port2-channel, 48 KHz, 16-bit
Audio Output via USB-A port2-channel, 48 KHz, 16-bit/24-bit/32-bit
Network
Ethernet1x RJ45 port, 10/100/1000 Mbps Base-T
Wi-Fi2.4G/5G, Station and Hotspot modes supported
CellularUSB modem supported (not supplied)
BluetoothBT 5.0
Storage
Local Storage64GB
SD Card (not supplied)FAT32 (Under 128G), NTFS, exFAT
Power
AC PowerPower Input: 12V/1.5A
Maximum power consumption: 15W
Battery Pack2x DC 7.4V (NP-F Battery Not Supplied), Hot-Swappable
LED Light
Battery IndicatorsGreen: 50% - 100%
Orange: 25% - 50%
Red: <25%
Off: Depleted
NDI Tally LightsRed: the NDI streaming signal is in PGM view.
Green: the NDI streaming signal is in PVW view.
Working Environment
Operating Temperature-10°C to 50°C
Storage Temperature-20°C to 70°C
Relative Humidity5% to 90% non-condensing
Basic Info
Dimensions147.2x90x28.5mm
WeightWith Mount: 495.2g
Without Mount: 402.9g
Manufacturer Code
OPB-2402-C
