Product Information
Theatrixx xVision 4K Converter HDMI2.0 to Fibre MultiMode opticalCON DUO
Professional equipment in mission-critical applications is all about reliability and confidence.
So Theatrixx started with a clean sheet, and built what might soon become your most trustworthy piece of equipment.
Introducing the world’s first video converters truly designed for the road. Video converters nowadays are used everywhere on professional A/V events, presentations, live shows and tours and often have a critical role.
Yet, they are often the weakest link in the signal chain. Low quality connectors, weak enclosure, external consumer-grade power supply, and overall barebones design that all contribute to a generally unreliable piece of equipment. Theatrixx wanted to change that, so they designed the xVision Video Converters.
Key Features:
- Integrated power supply with locking PowerCON connector
- Magnetic stacking system and non-skid rubber pad
- Multiple mounting options: C-Clamp, wall-mount adapter, LCD mount adapter and belt adapter
- Plug-n-play operation; No dipswitches, buttons or menus to fumble with: It just works
- Locking HDMI port prevents accidental disconnection
- Clear and ample status LED indicators for quick troubleshooting
- xVision HDMI to Fiber Converter (True1)
- Power Cable
| Connections | Video Input: HDMI 2.0 type A Ethernet Port: 1 Gbps Ethernet on Neutrik EtherCON Fibre Output: 10 Gbps Optical Ethernet, SFP-based, Multimode, OpticalCON DUO |
|---|---|
| Supported Signals | HDMI 2.0 input: All HDMI 2.0 formats including: 4K/60 8-bit 4:4:4, 4K/60 10-bit 4:2:2, High dynamic range (HDR10 & Dolby Vision) Embedded audio: Up to 8 channels, 24 bit, 192 kHz Encoding Technology: SDVoE (NT1000-based) Typical Latency: < 0.1 ms Auxiliary Signals: 1 Gbps Ethernet pass-thru |
| Environmental | Operating temp.: 0-40° C Relative Humidity: 0 % to 90 % RH non-condensing |
| Power Requirements | Power Supply: Built-in power supply PowerCON True1 in / loop thru Power Consumption: 45 W max. Operational Voltage Range: 100-240 V 50-60 Hz |
| Physical | Height: 62 mm (2.44 in) Depth: 18o mm (7.08 in) Width: 221 mm (8.7 in) Weight: 2 kg (4.4 lbs) |
