Theatrixx xVision 4K Converter HDMI2.0 to Fibre MultiMode opticalCON DUO

Availability:In stock
Cat No.
52561
SKU
THEH2FM2
Theatrixx

Order Now - Usually available to despatch in 7-10 days

Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. For urgent click and collect where products are showing in stock, please call us at 01442 292929 or email sales@proav.co.uk to check for availability.

Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. For urgent click and collect where products are showing in stock, please call us at 01442 292929 or email sales@proav.co.uk to check for availability.

£2,545.20 £2,121.00
- +
Apple Pay
  • Free UK Delivery

    Free UK Delivery

    On orders over £75

  • Price Match

    Price Match

    Request here

Product Information

Theatrixx xVision 4K Converter HDMI2.0 to Fibre MultiMode opticalCON DUO

Professional equipment in mission-critical applications is all about reliability and confidence.

So Theatrixx started with a clean sheet, and built what might soon become your most trustworthy piece of equipment.

Introducing the world’s first video converters truly designed for the road. Video converters nowadays are used everywhere on professional A/V events, presentations, live shows and tours and often have a critical role.

Yet, they are often the weakest link in the signal chain. Low quality connectors, weak enclosure, external consumer-grade power supply, and overall barebones design that all contribute to a generally unreliable piece of equipment. Theatrixx wanted to change that, so they designed the xVision Video Converters.

Key Features:

  • Integrated power supply with locking PowerCON connector
  • Magnetic stacking system and non-skid rubber pad
  • Multiple mounting options: C-Clamp, wall-mount adapter, LCD mount adapter and belt adapter
  • Plug-n-play operation; No dipswitches, buttons or menus to fumble with: It just works
  • Locking HDMI port prevents accidental disconnection
  • Clear and ample status LED indicators for quick troubleshooting
  • xVision HDMI to Fiber Converter (True1)
  • Power Cable
Connections Video Input: HDMI 2.0 type A
Ethernet Port: 1 Gbps Ethernet on Neutrik EtherCON
Fibre Output: 10 Gbps Optical Ethernet, SFP-based, Multimode, OpticalCON DUO
Supported Signals HDMI 2.0 input:
All HDMI 2.0 formats including: 4K/60 8-bit 4:4:4, 4K/60 10-bit 4:2:2,
High dynamic range (HDR10 & Dolby Vision)
Embedded audio: Up to 8 channels, 24 bit, 192 kHz
Encoding Technology: SDVoE (NT1000-based)
Typical Latency: < 0.1 ms
Auxiliary Signals: 1 Gbps Ethernet pass-thru
Environmental Operating temp.: 0-40° C
Relative Humidity: 0 % to 90 % RH non-condensing
Power Requirements Power Supply:
Built-in power supply
PowerCON True1 in / loop thru
Power Consumption: 45 W max.
Operational Voltage Range: 100-240 V 50-60 Hz
Physical Height: 62 mm (2.44 in)
Depth: 18o mm (7.08 in)
Width: 221 mm (8.7 in)
Weight: 2 kg (4.4 lbs)
