SWIT S-4604 3GSDI 1 to 4 Distributor

Availability:In stock
Cat No.
11179
SKU
S-4604
SWIT

Order Now - Usually available to despatch in 1-2 weeks

Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. For urgent click and collect where products are showing in stock, please call us at 01442 292929 or email sales@proav.co.uk to check for availability.

Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. For urgent click and collect where products are showing in stock, please call us at 01442 292929 or email sales@proav.co.uk to check for availability.

£237.60 £198.00
- +
Apple Pay
  • Free UK Delivery

    Free UK Delivery

    On orders over £75

  • Price Match

    Price Match

    Request here

Product Information

Swit S-4604 3GSDI 1 to 4 Distributor

Swit's S-4604 is a portable 3G/HD/SD-SDI distributor. It supports 1 SDI input, and 4 SDI output, with embedded audio.

The S-4604 features Power/Input/Output status indicators and is housed in heavy-duty housing. Various screw threads offer convenient installation and versatility for other accessories.

S-4604 is a mini converter for distributing 1 SDI input to 4 SDI output, supports up to 3Gb/s SDI, with all embedded information, widely used on broadcast projects.

Input and Output

1× 3G/HD/SD-SDI input
4× 3G/HD/SD-SDI output (Reclocked)

SDI Amplifier

The S-4604 features low SDI jitter and SDI re-clocking so that you can use several S-4604 to prolong the SDI transmission distance.

Status Indicators

S-4604 provides 3 LED indictors, to check if the power is connected, and if the input/output signal is delivered.

Power Supply

The mini converter is powered by a pole-tap DC socket. The package includes an AC-DC power adaptor, and you can also connect DC cable from 6-18V batteries.

Heavy-Duty Housing

The S-4604 mini converter adopts unibody aluminium alloy housing, strong for field using and protects the BNC connectors effectively.

Installation

S-4604 provides the bottom 1/4-inch screw threads for fixing on cameras, and an installing plate is supplied in the package, for fixing on the wall and binding the BNC cables.


Key Features:

  • Portable 3G/HD/SD-SDI 1 to 4 distributor
  • 1 SDI input, 4 SDI output
  • SDI re-clocking and amplifier
  • Power/input/output status indicator
  • Pole-tap 6-18V DC power input
  • Heavy-duty aluminium housing
  • Bottom screw threads for installing
  • Portable 3G/HD/SD-SDI 1 to 4 distributor
  • 1 SDI input, 4 SDI output
  • SDI re-clocking and amplifier
  • Power/input/output status indicator
  • Installation plate
  • AC-DC Adaptor
S-4604
Input BNC×1 3G/HD/SD-SDI input
Output

BNC ×4

3G/HD/SD-SDI loop output
Video Format SDI 1080p (60 / 59.94 / 50)
1080i (60 / 59.94 / 50)
1080p (30 / 29.97 / 25 / 24 / 23.98)
1080psf (30 / 29.97 / 25 / 24 / 23.98)
720p (60 / 59.94 / 50)
480i (59.94)
576i (50)
  HDMI 1080p (60/ 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98)
1080i (60 / 59.94 / 50)
720p (60 / 59.94 / 50)
480i / 576i
  Audio 48KHz Sync
Power ≤2W
Working Voltage DC 6-18V
Working Environment Temperature: 0°C-+70°C, Humidity:10%-90%
Dimensions 105×84×29 mm
Net weight 240g
