Product Information

Sound Devices MixPre-10 II

8 Preamp, 12 Track, 32-Bit Float Audio Recorder

Complex Productions, Simplified

Versatile. Durable. High-Performance.

If you record field audio, sound effects, audio for film, live music, or are just starting your audio journey, the MixPre-10 II is for you! With eight crystal-clear, ultra low-noise Kashmir preamps, you can record multiple actors, multiple podcasters, or audio for film with superior quality – all the way up to a 32-bit float bit depth and a 192 kHz sample rate. This newest generation of Sound Devices’ award-winning MixPre Series has been redesigned for increased performance and an astounding 142 dB of dynamic range.

Your MixPre-10 II is highly customizable to your needs. Record internally to a compatible SD card on set or stream your podcast over USB to your computer at home. Power with your computer, wall power, or record in the middle of nowhere with AA or Sony L-mount batteries. Adjust limiters, bit depth, sample rates, gain, pan, low-cut, phase inversion and phantom power to your liking. Stay in sync with your camera using the internal timecode generator, or feed timecode in via HDMI, Aux In, or BNC. The choice is yours!

Professionals love the flexibility of the MixPre Series. Don’t need all those options? Basic mode has you covered.

Your MixPre-10 II is rugged, lightweight, and small, so you can throw it in a bag or mount it to a tripod or camera – or get situated on set with our Wingman App and one of our four supported USB control surfaces. With the superior sound and build quality that you can expect from the industry leader in production audio recording, your MixPre-10 II can capture audio for any application. Our friendly and knowledgeable support team, based in the USA and Germany, is here for all your questions and comments. Our job is to make your job easier.

  • Eight ultra-low-noise Kashmir microphone preamps with adjustable limiters capture high quality audio in the field, on set, or with a computer.
  • Create a mix using the built-in 10 x 4 portable mixer.
  • Record up to 12 tracks to an SD card and backup to a USB thumb drive.
  • 12-in, 4-out USB audio interface streams to your computer via USB-C.
  • Choose bit depths from 16 to 32-bit float, and sampling rates from 44.1 kHz to 192 kHz.
  • Internal LTC timecode generator. Timecode In/Out via BNC or Aux In/Stereo Out.
  • Timecode and record triggering via HDMI.
  • USB-A for control surfaces, keyboards, and auto-copy to USB drive.
  • In-unit ISO mixing, gain, pan, low-cut, phase inversion, and phantom power.
  • Sunlight-readable color touch screen and LED metering.
  • Lightweight, durable, and small: perfect for bag use, mobile recording, or a home studio.
  • Powerful 300 mW+300 mW headphone amp allows clear and accurate reference of audio.
  • Includes a MX-8AA Battery Sled (batteries not included), XL-WPH3 AC Power Supply, and USB-C to USB-C cable.
Audio Inputs
Frequency Response 10Hz to 80kHz +/- 0.5dB re 1kHz @ 192kHz sample rate
THD + Noise 0.005% max (@1 kHz, 22-22 kHz BW, gain= 20 dB, -10 dBu in)
ADC 32 bit precision; 142 dB dynamic range min (A weighted, gain = 10 dB, fader = 0 dB)
Equivalent Input Noise -130 dBV (-128 dBu) max (A-weighting, gain = 76 dB, 150 ohm source impedance)
Inputs
  • Mic: XLR active-balanced; 4k input
  • Line: XLR active-balanced; 4k input
  • Aux/Mic in: 3.5mm TRS, 2-channel unbalanced; 100k input
  • Line: ¼-inch TRS active-balanced; 4k input
  • USB Audio: 4 channels
  • All inputs fully RF-filtered and overload protected.
Gain
  • Mic input: +6dB to +76dB
  • Line input: -20dB to +30dB
  • Fader: -inf to +20dB
  • Headphone: -inf to +20dB
  • Total, Mic-to-recording (max): +96dB
  • Aux In (Mic): Gain = +10dB to +40dB
  • Aux In (Line): Gain = -10dB to +20dB
  • Total Aux Gain including Fader (Mic-to-recording): +60dB
Maximum Input Level
  • Mic XLR: +14dBu (limiters on or off)
  • Line XLR/¼-inch: +28dBu (limiters on or off)
  • Aux In (Mic): -10dBu
  • Aux In (Line): +10dBu
Low Cut Filters 40 Hz to 160 Hz (adjustable), 18 dB/oct. First stage analog, subsequent stages digital.
Microphone Powering
  • Mic XLRs: 48V via 6.8k resistors, 10mA each
  • Mic 3.5mm: 3V @ 3k source
Limiters Limiter at all gain stages, range > 40dB. First stage analog, subsequent stages digital. Adjustable Threshold, Ratio, and Release.
Audio Outputs
DAC feeding Stereo Out, Headphone Out

32 bit precision; 115dB dynamic range (A-weighted)

L/R Out TA3 2-channel balanced, 1.1K max output impedance, +18 dBu max output level
X1/X2 Out 3.5mm TRS stereo unbalanced, 500 ohm output impedance, +7.8dBu max output level
Headphones Out 3.5mm TRS stereo unbalanced, 300mW + 300mW, for use with any impedance headphones
USB
  • Audio Interface (USB-C): 12-in/4-out; 44.1 to 96 kHz; 16/24-bit; Class-compliant USB 2.0 high speed or ASIO® driver (supplied via download)
  • Mass Storage (USB-C): USB 2.0 high speed
  • Keyboard (USB-A): Text entry and control
  • Thumbdrive (USB-A): Manual or auto-copy to drive
  • Midi Control Surface (USB-A)
Recording
Maximum Record Tracks 12 Tracks: Stereo mix + 10 ISOs
Sampling Frequency
  • 44.1 kHz
  • 47.952 kHz
  • 48 kHz
  • 48.048 kHz
  • 96 kHz
  • 192 kHz
Bit Depth
  • 16
  • 24
  • 32 Float
Recording Storage
  • Type: SD, SDXC, SDHC Card (USB thumbdrive, copy only)
  • Max Storage Size: 512 GB (SDXC)
  • Card format: exFAT
File Type Polyphonic WAV
Timecode
Timecode Modes
  • Free Run
  • Time of Day (file stamped w/current ToD)
  • Rec Run
  • Ext LTC (file stamped w/incoming LTC on BNC or Aux 3.5mm)
  • Camera TC (file stamped w/incoming TC from cameras that output TC)
Timecode Frame Rates
  • Auto-detects (fps): 23.98 (same as 23.976)
  • 24
  • 25
  • 29.97DF
  • 29.97ND
  • 30
  • 30DF
Sync Source
Internal, Word Clock, Ext LTC
BNC In (TC In)
  • Switchable between Timecode (default) or Word Clock Input
  • Timecode: 20k ohm impedance, 0.3 V - 3.0 V p-p (–17 dBu - +3 dBu)
  • Word Clock: 10k ohm impedance, 1.5V p-p
BNC Out (TC Out)
  • Switchable between Timecode (default) or Word Clock Output
  • Timecode: 1k ohm impedance, 3.0V p-p (+12 dBu)
  • Word Clock: 75 ohm impedance, 5V p-p
HDMI
TC Reader via HDMI
Remote Control
  • Bluetooth LE: Wireless control using Wingman app
  • HDMI (micro): Auto-record start/stop trigger from cameras that output record flag over HDMI
  • Timecode: Auto-record start/stop trigger via Aux In timecode
Touch Screen 320x256; 1.6-inch, color, sunlight-viewable IPS LCD
Power
  • AA Batteries: 8x AA sled (included). NiMH recommended
  • L-Mount: Optional sled for 2x (hot-swappable) Li-ion batteries
  • AC Adapter: XL-WPH3 (included): Universal, 45 W in-line AC-to-DC power supply Hirose 4-pin DC plug, with detachable IEC power cord. 100-240, 50/60Hz
Environmental
  • Operating: -20°C to 60°C, 0 to 90% relative humidity; (non-condensing)
  • Storage: -40°C to 85°C
Dimensions and Weight
  • Dimensions: 36 mm x 206 mm x 175 mm (H x W x D); 1.375” x 8.125” x 6.875”
  • Weight: 0.91 kg; 32.1 oz. (unpackaged, without batteries)
