INPUTS: 2 HDMI on HDMI connectors, 1 VGA on a 15−pin HD (F) connector, 1 unbalanced stereo audio 1V RMS (nominal) on a 3.5mm mini jack.
OUTPUTS: 1 HDBaseT on an RJ−45 connector, 1 unbalanced stereo audio 1V RMS (nominal) on a 3.5mm mini jack.
PORTS: 1 Ethernet on an RJ−45 connector, 1 RS−232 3−pin terminal block control port, 1 RS−232 3−pin terminal block data port, 1 USB on mini USB connector.
CONTROLS: Remote switches for input switching, step−in, volume control, and device reset switch.
STANDARDS: HDMI with Deep Color, x.v.Color™ and 3D; HDCP—works with sources that support HDCP repeater mode; HDBT certified.
MAXIMUM ANALOG AUDIO LEVELS: 3.1Vpp.
THD: –75dBu.
SNR: 0.013%.
SUPPORTED WEB BROWSERS
Windows 7 and higher: Internet Explorer (32/64 bit) version 11, Firefox version 30, Chrome version 35; MAC: Chrome version 35, Firefox version 27, Safari version 7; Android OS: Chrome version 35; iOS:Chrome version 35, Safari version 7.
MAXIMUM TRANSMISSION DISTANCE: 180m (590ft) up to 1080p @60Hz @24bpp in extended mode, 130m (430ft) up to 1080p @60Hz @36bpp in normal mode.
POWER CONSUMPTION: 48V DC, 630mA.
OPERATING TEMPERATURE: 0° to +40°C (32° to 104°F).
STORAGE TEMPERATURE: –40° to +70°C (–40° to 158°F).
HUMIDITY: 10% to 90%, RHL non−condensing.
COOLING: Convection.
ENCLOSURE TYPE: Aluminium.
DIMENSIONS: 18.75cm x 11.5cm x 2.54cm (7.38” x 4.53” x 1.0”) W, D, H.
ENVIRONMENTAL REGULATORY COMPLIANCE: Complies with appropriate requirements of RoHs and WEEE.
INCLUDED ACCESSORIES: Power adapter 48V DC 1.36A, ADC−DPM/HF DisplayPort (M) to HDMI (F) adapter cable, power cord.
WARRANTY: 7 years parts and labor.
DIAGRAM
