Litepanels Gemini 2x1 RGBWW LED Quad Array Kit - UK

Availability:In stock
Cat No.
49723
SKU
940-2203
Litepanels

Order Now - Usually available to despatch in 7-10 days

£17,634.00 £14,695.00
- +
  • Free UK Delivery

    Free UK Delivery

    On orders over £250

  • Price Match

    Price Match

    Request here

Product Information

Litepanels Gemini 2x1 RGBWW LED Quad Array Kit - UK

The Gemini 2x1 Hard Quad Array Light Kit provides ultimate power and versatility.

Complete with 4x Gemini 2x1 Hard panels, quad yoke, bracket, and hardware to support four Gemini light fixtures in a 4x2 configuration for use as a single large light source measuring approximately 51x25".

This array includes a steel 1 1/8" Jr pin to be used in heavy duty light stands and grip.

Key Features:

  • Combines 4x Gemini 2x1 Hard panels in an array to create a very large, powerful source of quality lighting
  • Fast assembly - utilises the Gemini 2x1's yoke channel
  • Control all Geminis with one menu via Master/Replica mode in settings with daisy chain of DMX (RJ45 Cat 5 or 5-Pin XLR)
  • Wireless control via CRMX
  • Combines 4x Gemini 2x1 Hard panels in an array to create a very large, powerful source of quality lighting
  • Fast assembly - utilises the Gemini 2x1's yoke channel
  • Control all Geminis with one menu via Master/Replica mode in settings with daisy chain of DMX (RJ45 Cat 5 or 5-Pin XLR)
  • Wireless control via CRMX
  • 4x Gemini 2x1 Hard UK Power cable (940-2101)
  • 1x Quad Gemini 2x1 stacking Kit with Yoke (900-3604)
  • 3x RJ45 connector
  • 3x AC power-thru cable
LED PanelRGBWW
Beam angle (no diffuser)20°
Beam angle with Domed Diffuser>100°
Optics20° custom TIR lens
CCT Range2,700-10,000K
Daylight (5600K) (Lux @10ft/3m)23,000 (No diff)
8,000 (Ultra Light diff)
2,800 (Domed diff)
Tungsten (3200K) (Lux @10ft/3m)20,000 (No diff)
6,700 (Ultra Light diff)
2,300 (Domed diff)
RED (Lux @10ft/3m)2,700 (No diff)
