Kino Flo FreeStyle Air Mini RGB LED Light Panel (DMX System Universal Kit)
Availability:In stock
Cat No.
60520
SKU
SYS-FAMINI
Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. For urgent click and collect where products are showing in stock, please call us at 01442 292929 or email sales@proav.co.uk to check for availability.
Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. For urgent click and collect where products are showing in stock, please call us at 01442 292929 or email sales@proav.co.uk to check for availability.
£3,415.20
£2,846.00
-
Free UK Delivery
On orders over £75
-
Price Match
Request here
Product Information
Kino Flo FreeStyle Air Mini RGB LED Light Panel (DMX System Universal Kit)
The FreeStyle Air Mini arrives ready to take its place as a lightweight accessory that integrates seamlessly with existing FreeStyle systems. Compatible with FreeStyle mounts, extension cables and LED-140 & LED-150 Series controllers, this portable thin profile panel offers the advantages of easy deployment and favourable cost of ownership to current FreeStyle owners and operators.
In addition to a twist-on mount for light stands, and corner bumpers for 4-point hangs, the FreeStyle Air Mini comes with eyelets to simplify overhead and other surface attachments. Its rigid construction prevents any flex when handling and safeguards the integrity of its components. Usable LED life is extended with a proven passively cooled design that ensures colour and luminosity remain stable over the rated life of the LEDs.
Ease of maintenance is built into a user-serviceable design. It features a removable upper rail and quick access to pull-out LED platens that are easily replaced or repaired.
Combining new mobility and reliable performance with familiar features, the FreeStyle Air Mini delivers Kino Flo’s renowned Color Science LED technology in this lightweight addition to the range.
- Kelvin presets & custom settings, 2500K-9900K
- Dimming without color shift
- Green/Magenta control
- Dial in any colour through Hue Angle and Saturation control
- Kino Flo presets and Gels
- RGB, CIE xy, FX (Effects) control
- Camera Profiles (LUTs), Color Space
- Manual & DMX Dimming, DMX wireless (Lumen Radio)
- 1x PAN-AMINI FreeStyle Air Mini LED Panel
- 1x LED-140X-230U FreeStyle 140 LED DMX Controller, Univ 230U
- 1x X12-F425 FreeStyle/4 Extension, 25ft
- 1x MTP-BG41S KinoGrip 41K Mount w/ Baby Receiver Short (16mm)
- 1x DOP-DFS-SXLM1 SNAPBOX® for Kino Flo Air Mini
| Light Fixture | |
|---|---|
| Item Type | 1x LED Light Panel |
| Included Storage Case | No |
| Photometrics | 6500K: |
| 183 fc / 1970 Lux at 3.3' / 1 m | |
| 21 fc / 233 Lux at 9.8' / 3 m | |
| 7 fc / 86 Lux at 16.4' / 5 m | |
| Color Temperature | 2500 to 9900K |
| Color Modes | RGB, Daylight, Tungsten |
| Dimming | Controller Not Included |
| • 1 to 100% | |
| Cooling System | Passive |
| Built-In Flash | No |
| Umbrella Mount | No |
| Front Accessory Mount | Proprietary |
| Connectivity | |
| Mobile App Compatible | No |
| Power & I/O | |
| Power Source | AC Power (Cable Not Included) *Requires Power Supply/Controller (Not Included) |
| Battery (Not Included) *Requires Power Supply/Controller (Not Included) | |
| Inputs/Outputs | 1x Built-In Cable with Unspecified Power Input |
| Power Pass-Thru | No |
| Power Consumption | 55 W |
| Mounting | |
| Fixture Mounting | Proprietary |
| Environmental | |
| Environmental Protection | Dust-Resistant (IP20) |
| General | |
| Display | No |
| Dimensions | 21 x 13 x 2" / 53.3 x 33 x 5.1 cm |
| Weight | 3 lb / 1.4 kg |
| Kino Flo FreeStyle 140 LED DMX Controller For FreeStyle T44 Bulbs, (120 VAC Cord) Specs | |
| Connections | Power |
| AC Input: IEC Connector | |
| DC Input: 3-Pin XLR | |
| DMX In & Out: 5-Pin XLR (Male & Female) | |
| USB: Mini-B | |
| Dimming Range | 100 to 1% Brightness |
| Power | Voltage |
| AC: 120 to 240 VAC, 50/60 Hz | |
| DC: 18 to 36 VDC, 150 W | |
| Draw | |
| AC: 1.25 A @ 120 VAC | |
| DC: 6.25 A @ 24 VDC | |
| Fuse | |
| 3.15 A/250 V | |
| Dimensions | 9.5 x 4.5 x 2.5" / 24.13 x 11.43 x 6.35 cm |
| Weight | 4.5 lb / 2.04 kg |
| Packaging Info | |
| Package Weight | 4.72 lb |
| Box Dimensions (LxWxH) | 12.5 x 10 x 3" |
