Gefen VGA KVM over IP - Receiver Package

Gefen 4K Ultra HD 600 MHz 1:8 Splitter w/ HDR – with Power Cord for Swiss territories

Designing systems capable of distributing 4K Ultra High Definition media requires support for the content of today, and headroom for the content of tomorrow. The Gefen EXT-UHD600-18 splitter distributes signal from one 4K source, and distributes it to up to eight 4K displays or video zones. The splitter features a 1U tall, rack-mountable enclosure that can also be placed on a shelf. It also accommodates Gefen locking HDMI cables for secure connections.

Video Support

Gefen’s Ultra HD 600MHz Series of splitters take HDMI 2.0 to its highest specification of 4K 60 Hz at 4:4:4 chroma subsampling, along with HDR (High Dynamic Range) support. They go beyond the requirements of typical 4K systems, delivering stunning Ultra HD and DCI/Cinema picture up to 4096 x 2160 pixels at 60 frames per second without subsampling color. This ensures that the scene shown on the display is every bit as brilliant as the picture that the camera captured. HDR lets every subtle nuanced gradation of each pixel play out across the screen in immersive clarity. Gefens Ultra HD 600MHz Series creates a seamless bridge between the digital media of yesterday, today, and tomorrow. Supporting the digital rights management standa(more…)



• Split a Dual Link DVI signal to two DVI Dual Link outputs



• Allows simultaneous display of source on two screens



• Supports Single Link DVI resolutions up to 1920 x 1200, and dual-link up to 3840 x 2400



• Auto EQ compensates for any imperfections in the image



• Power On indicator



• DVI Link indicators



• Supports DDWG standard for DVI-compliant monitors



• HDCP pass-through on output #1

Video Input connector (Sender): (1) VGA HD-15, female

Video Output connector (Sender): (1) VGA HD-15, female

Video Output connector (Receiver): (1) VGA HD-15, female

Line Input (Sender): (1) 3.5mm mini-stereo jack

Line Output (Sender): (1) 3.5mm mini-stereo jack

Mic Input (Receiver): (1) 3.5mm mini-stereo jack

Headphones/Line Output (Receiver): (1) 3.5mm mini-stereo jack

USB Host Interface port (Sender): (1) USB Type B, female

USB Device ports (Receiver): (2) USB 2.0 Type A, female
: (2) USB 1.1 Type A, female

RS-232 port (Sender): (1) DB-9, female

RS-232 port (Receiver): (1) DB-9, male

IR Sensor (Receiver): (1) Located on front panel

IR In/Ext (Sender/Receiver): (1) 3.5mm mini-stereo jack

IR Out (Sender/Receiver): (1) 3.5mm mini-mono jack

IR Extender type: EXT-RMT-EXTIRN

Ethernet port (Sender): (1) RJ-45, shielded, PoE

Ethernet ports (Receiver): (2) RJ-45, shielded, one with PoE

Channel Up/USB-Request button (Receiver): (1) tact-type

Channel Down button (Receiver): (1) tact-type

Mode button (Sender): (1) tact-type, recessed

Reset button (Sender/Receiver): (1) tact-type, recessed

Program button (Sender/Receiver): (1) tact-type, recessed

Program Select switch (Sender/Receiver): (1) slide-type, recessed

Link Indicator (Sender/Receiver): (1) LED, green

Power Indicator (Sender/Receiver): (1) LED, blue

Power Supply jack (Sender/Receiver): 5V DC, 2.5mm pin and 5.5mm barrel, locking

Power Requirement (Sender/Receiver): 5V DC, or PoE (802.3af standard)

Power Consumption: Sender: TBD
: Receiver: TBD

Operating Temperature (Sender/Receiver) +32 to +122°F (0 to +50°C)

Operating Humidity (Sender/Receiver) 5% to 90% RH, non-condensing

Storage Temperature (Sender/Receiver) -4 to +185°F (-20 to +85°C)

Storage Humidity (Sender/Receiver) 0% to 95% RH, non-condensing

MTBF: Sender: 50000 hours
: Receiver: 50000 hours

Dimensions (W x H x D, without connectors or feet):
Sender: 8.4″ x 1.7″ x 5.9″ (214mm x 43mm x 150mm)
: Receiver: 8.4″ x 1.0″ x 5.9″ (214mm x 25mm x 150mm)

Unit Weight: Sender: TBD
: Receiver: TBD

Shipping Weight: Sender: TBD
: Receiver: TBD

* Features and specifications are subject to change without notice
** Pending features to be activated via an upcoming firmware update
