Gefen DVI KVM over IP - Receiver Package

Gefen 1:4 DVI Splitter – with Power Cord for Swiss territories

DVI (Digital Visual Interface) is a common connector used throughout the industry to connect digital video displays to video sources such as computers.

Gefen’s 1:4 DVI Splitter is a distribution hub that sends the same DVI graphics source to up to four DVI digital displays (flat panels or projectors). It is a reliable solution that accommodates four digital video displays at the same time, creating a multi-viewing environment that maintains the highest resolution video at all times.

The Gefen EXT-DVI-144N 1×4 DVI Splitter distributes a single DVI source to up to four DVI dual link outputs without losing quality or resolution. It works with any dual link DVI computer supporting internal, downstream, and custom EDIDs. This product can be placed on a shelf or other horizontal surface, or be mounted in a standard 19-inch wide rack, using the included rack ears.

Video Support

Resolutions up to the highest DVI single link resolution of 1920 x 1200 are supported.

• Extends any S/PDIF and TOSLINK® digital audio device up to 330 feet (100 meters) from the source





• Supports multichannel digital audio like Dolby® Digital 5.1, DTS, and Dolby® TrueHD





• Supplies clear digital audio over long distances as if connected locally





• Streamlines audio installations by allowing source devices to be located in off-site or unseen rack





• One CAT-5e cable used for extension





• Audio is transmitted digitally for zero signal loss



Video Input connector (Sender): (1) DVI 29-pin, female, digital only

Video Output connector (Sender): (1) DVI 29-pin, female, digital only

Video Output connector (Receiver): (1) DVI 29-pin, female, digital only

Line Input (Sender): (1) 3.5mm mini-stereo jack

Line Output (Sender): (1) 3.5mm mini-stereo jack

Mic Input (Receiver): (1) 3.5mm mini-stereo jack

Headphones/Line Output (Receiver): (1) 3.5mm mini-stereo jack

Optical Digital Audio Output (Receiver): (1) TOSLINK ®

USB Host Interface port (Sender): (1) USB Type B, female

USB Device ports (Receiver): (2) USB 2.0 Type A, female

: (2) USB 1.1 Type A, female

RS-232 port (Sender): (1) DB-9, female

RS-232 port (Receiver): (1) DB-9, male

IR Sensor (Receiver): (1) Located on front panel

IR In/Ext (Sender/Receiver): (1) 3.5mm mini-stereo jack

IR Out (Sender/Receiver): (1) 3.5mm mini-mono jack

IR Extender type: EXT-RMT-EXTIRN

Ethernet port (Sender): (1) RJ-45, shielded, PoE

Ethernet ports (Receiver): (2) RJ-45, shielded, one with PoE

Channel Up/USB-Request button (Receiver): (1) tact-type

Channel Down button (Receiver): (1) tact-type

Mode button (Sender): (1) tact-type, recessed

Reset button (Sender/Rece(more…)
