Gefen 4K Ultra HD 8x9 Matrix for HDMI w/ HDCP 2.2, HDBaseT, & POH
Availability:In stock
Cat No.
98231
SKU
GEF-UHD-89-HBT2
Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. For urgent click and collect where products are showing in stock, please call us at 01442 292929 or email sales@proav.co.uk to check for availability.
Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. For urgent click and collect where products are showing in stock, please call us at 01442 292929 or email sales@proav.co.uk to check for availability.
£11,100.00
£9,250.00
-
Free UK Delivery
On orders over £75
-
Price Match
Request here
Product Information
Gefen 4K Ultra HD 8x9 Matrix for HDMI w/ HDCP 2.2, HDBaseT, & POH
- Shipping Info
- Length0 (Inches)
- Width0 (Inches)
- Height0 (Inches)
- Weight0 (Lbs)
- UPC888814402001
- Other Specifications
- Maximum Pixel Clock:300 MHz
- Matrix:
- HDMI Input Connectors: (8) Type A 19-pin female, locking
- HDMI Output Connector: (1) Type A 19-pin female, locking
- HDBaseTà¢Ã¢â‚¬Å¾Ã‚ ¢ 2.0 POH Output Connectors: (8) RJ-45
- RS-232 serial port- control: (1) DB-9, female
- RS-232 serial ports- extension: (8) 3.5mm mini-stereo jack
- IR In/Ext Ports- extension: (9) 3.5mm mini-stereo jack
- IR In/Ext Port- control: (1) 3.5mm mini-stereo jack
- IR Out Ports- extension: (9) 3.5mm mini-mono jack
- Ethernet Port- IP Control & extension: (1) RJ-45
- AC Power Inlet: (1) IEC type
- IR Extender type: EXT-RMT-EXTIRN (not included)
- IR Sensor: (1), located on front panel
- Display: OLED, 2 rows, 20 characters per row
- Power Button/Indicator: (1) tact-type, bi-color blue/orange backlight
- Control Buttons/Indicators: (7) tact-type, blue backlight
- Power Supply: 100V to 240V AC
- Rack mounting requirements: Standard 19″ rack, 2U high
- Dimensions (excluding rack ears and connectors, W x H x D): 17.25″ x 3.5″ x 15.75″ (440mm x 89mm x 400mm)
- Net Unit Weight: 22 lbs. (10.0 kg)
- Receiver:
- HDMI Output Connector: (1) Type A 19-pin female, locking
- HDBaseT 2.0 POH Input Connector: (1) RJ-45
- RS-232 serial port- extension: (1) 3.5mm mini-stereo jack
- IR In/Ext Port- extension: (1) 3.5mm mini-stereo jack
- IR Out Port- extension: (1) 3.5mm mini-mono jack
- Ethernet Port- extension: (1) RJ-45
- IR Extender type: EXT-RMT-EXTIRN (not included)
- Dimensions (excluding brackets and connectors, W x H x D): 3.50″ x 0.65″ x 5.65″ (88mm x 16mm x 143mm)
- Net Unit Weight: 0.6 lbs. (0.25 kg)
- System:
- Power Consumption: 175W
- Operating Temperature: +32 to +122  °F (0 to +50  °C)
- Operating Humidity: 5% to 90% RH, non-condensing
- Storage Temperature: -4 to +140  °F (-20 to +60  °C)
- Storage Humidity: 5% to 95% RH, non-condensing
- MTBF: 50000 hours
- In The Box
- 4K Ultra HD 8×8 Matrix for HDMI w/ HDCP 2.2, HDBaseT, & POH (GEF-UHD-89-HBT2)(1)
- 4K Ultra HDBaseT Receiver HDCP 2.2 & POH w/ Ethernet, RS-232, & 2-way IR (GEF-UHD-HBT2)(8)
- IR Remote Control (RMT-89)(1)
- Mini Phone to DB9 adapter (M-F) (ADA-MP-2-DB9-MF-AB)(8)
- Mini Phone to DB9 adapter (M-M) (ADA-MP-2-DB9-MM-AB)(8)
- IEC-type AC Power Cord (CAB-POWERCORD-xx)(1)
- Set of Rack Ears (RACK-AB-2U-BLK)- attached(1)
- L-shaped Brackets (BKT-L-401510-AB)(16)
- Screws for BKT-L-401510-AB (SCR-M3-05-06-PFH-ZP-AB)(40)
- Brackets for Locking HDMI (BKT-HD-LCK-100418-BZP-AB) (8)
- Quick-Start Guide (QSG-GEF-UHD-89-HBT2)(1)
