Gefen 4K Ultra HD 600 MHz Extender for HDMI over one Fiber-Optic Cable
Availability:In stock
Cat No.
98009
SKU
EXT-UHD600-1SC
Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. For urgent click and collect where products are showing in stock, please call us at 01442 292929 or email sales@proav.co.uk to check for availability.
Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. For urgent click and collect where products are showing in stock, please call us at 01442 292929 or email sales@proav.co.uk to check for availability.
£2,893.20
£2,411.00
-
Free UK Delivery
On orders over £75
-
Price Match
Request here
Product Information
Gefen 1:4 DVI Dual Link Splitter – with Power Cord for Swiss territories
The Gefen EXT-DVI-144DL 1×4 DVI Dual Link Splitter distributes a single dual link DVI source to up to four DVI dual link outputs without losing quality or resolution. It works with any dual link DVI computer supporting internal, downstream, and custom EDIDs. This product can be placed on a shelf or other horizontal surface, or be mounted in a standard 19-inch wide rack, using the included rack ears
Video Support
Resolutions up to 2560 x 1600 (WQXGA) and 3840 x 2160 (QFHD).
Serial Control
When not in use, it can be put in stand-by mode via RS-232. This reduces power consumption to less than 0.5W. EDID Management, output masking, and firmware updates can also be done via RS-232.
- Extends any unbalanced analog audio device up to 1000 feet (300 meters) from the source
- One CAT-5e cable used for extension
- Bidirectional transmission for speaker and mic
Maximum TMDS Clock: 600 MHz
Total Signal Bandwidth/Data Rate: 18.2 Gbps
Video Input connector: (1) HDMI Type A 19-pin female
Video Output connector: (1) HDMI Type A 19-pin female
Link connector (Sender/Receiver): (1) Type SC
Link Indicator (Sender/Receiver): (1) LED, green
Power Supply connector (Sender/Receiver): (1) 5V DC 3.5mm barrel/1.3mm pin   Â
Power Consumption: Sender: 3.2W, Receiver: 2.8W
Optical Power Budget: 6.5 dB
Operating Temperature: +32 to +122  °F (0 to +50  °C)
Operating Humidity: 10% to 85% RH, non-condensing
Storage Temperature: -4 to +158  °F (-20 to +70  °C)
Storage Humidity: 10% to 85% RH, non-condensing
MTBF: 50000 hours
Dimensions (W x H x D, Sender/Receiver, not including connectors):
1-3/4� x 7/8� x 3-1/8� (45mm x 22mm x 79mm)
Net Weight (Sender/Receiver): 3.2 oz. (0.1 kg) each
Shipping Weight: 2.5 lbs (1.2 kg)
* Features and specifications are subject to change without notice.
