Tascam MM-4D/IN-X 4-Channel Mic/Line Input Dante Converter

The MM-4D/IN-X is a compact converter that converts 4-channel mic/line input signals into Dante signals.

With half the size of a standard 1U rack, the MM-4D/IN-X is suitable for different Dante systems as an exquisite analog output unit.

The built-in DSP mixer enables small scale systems to fully perform with a variety of input/output models the TASCAM Dante Compact Processor Series offers. MM-4D/IN-X supports up to 96kHz/24bit and uses XLR connectors for analog mic/line input.

The MM-4D/IN-X has installed two natural-sounding, high grade TASCAM mic preamps made with all the knowledge and experience cultivated through the years in the making of pro audio equipment. Input range covers from -70 dBu to +26 dBu, with equivalent input noise achieving less than -125 dB, and signal-noise ratio over 108 dB.

Using the built-in matrix mixer, users can mix up to 8 different sources (4-channel mic/line inputs with 4-channel Dante inputs) and configure the settings on each of the four output zones.

The matrix mixer is also equipped with a ducking function and an ambient noise compensator function, which detects the level of environmental sounds and automatically adjusts the input level of the source.

Key Features:

  • 4-channel mic/line input with phantom power (+48v) support
  • Supports remote mic gain control
  • 4 Dante input/output
  • Supports PoE (Power over Ethernet)
  • Up to 24bit/96kHz
  • Includes a variety of DSP functions for optimal use in different scenes/environments (Output effects, 8 in/4 out matrix mixer)
  • Supports Dante daisy chain; this allows two Dante Compact Processor models to be connected without a network switch
  • Compatible with Dante Domain Manager and Dante AES67 Mode
  • Flexible scene preset function allows to work in different area situations (Up to 50 presets)
  • Timer event function allows to automatically switch scenes at a specified time (planned to be compatible on a future version update)
  • 2 types of user control software available for Windows/Mac/iOS/Android devices:
  • For integrators: input/output routing selection, DSP/design/scene settings of the complete system, etc.
  • For end-users: simple app design for only the necessary functions such as area volume settings, etc.
  • Remote control via Dante
  • Half-rack mountable size
  • Equipped with indicators that show LAN/Dante connection status and sample rate
  • Equipped with signal indicators that monitor line input signals
  • Configurable reference level (via remote control only)
  • Surface rack mountable angles for installation under desks included
  • 4-channel mic/line input with phantom power (+48v) support
  • Supports remote mic gain control
  • 4 Dante input/output
  • Supports PoE (Power over Ethernet)
General 44.1/48/88.2/96kHz,16/24-bit, 4 channels
Input/output ratings Connector RJ-45
Transmission protocol Dante
Gigabit Ethernet standard 1000BASE-T (IEEE 802.3ab)
Cables category 5e or faster STP cables
ANALOG IN connectors Connector XLR-3-31 (1: GND, 2: HOT, 3: COLD)
Minimum input level -70 dBu
Maximum input level +26 dBu
Input impedance 2.0 kΩ or higher
Other Power PoE class 0
TASCAM PS-P1220E AC adapter (sold separately)
Power consumption 7.5W
Dimensions 214 x 44.45 x 136.1 mm (W x H x D, including protrusions)
Weight 885 g
Operating temperature range 0°C-40°C
MIC IN → DANTE OUT Mic amp EIN (equivalent input noise) -125 dBu (150Ω, 22kHz LPF+A, JEITA)
Frequency response +/-0.5 dB: 20 Hz - 20 kHz(44.1/48kHz sampling frequency, JEITA)
+/-0.5 dB: 20 Hz - 40 kHz(88.2/96kHz sampling frequency, JEITA)
Distortion (THD+N) 0.003 %(when -1 dBFS input, 44.1/48/88.2/96kHz samplingfrequency, JEITA)
S/N ratio 108 dB (44.1/48/88.2/96kHz sampling frequency, JEITA)
Crosstalk 100 dB (44.1/48/88.2/96kHz sampling frequency, JEITA)
Dynamic range 108 dB (44.1/48/88.2/96kHz sampling frequency, JEITA)
