Product Information
Sonifex RB-DDA6A Digital Distribution Amp
The Sonifex Redbox RB-DDA6A digital distribution amplifier is used for distributing digital audio data/signal in AES/EBU format, repeating both the audio data and the status information of the input whilst re-normalising to standard digital audio levels.
It has a single XLR-3 female AES/EBU audio input which is distributed to 6 XLR-3 male AES/EBU outputs.
Applications for the RB-DDA6A include distributing audio from a digital mixing desk to multiple digital recorders, or feeding multiple studios with an output from a DAT machine.
It can accept input sample rates in the range of 30kHz - 100kHz, and bit rates of 16, 20 and 24 bit. It can be used for standard CD signal distribution at 16 bit 44.1kHz, as well as for high quality 24 bit 96kHz recording.
- 6 x Balanced XLR outputs
- 1 x Balanced XLR input
- Many applications
- Input Impedance 110 ohms +\-20% balanced
- Output Impedance 110 ohms +\-20% balanced
- Sample Freq. Range 30-100KHz
- Signal Level Balanced Min 3V peak to peak, Max 10V peak to peak
Connections
- Input 1 x AES/EBU XLR 3 pin female (balanced)
- Outputs 6 x AES/EBU XLR 3 pin male (balanced)
- Mains input Filtered IEC, switchable 110-120V, or 220-240V, fused, 6W max
Physical Specification
- Weight Nett: 0.95kg
- Gross: 1.4kg
- Dimensions Raw: 28cm (W) x 10.8cm (D) x 4.2cm (H)
- Boxed: 36cm (W) x 20.5cm (D) x 6cm (H)
