Product Information
Sonifex RB-DA6 6 Way Stereo Distribution Amplifier
The RB-DA6 is a 1U rack-mount high performance 6 way stereo distribution amplifier for splitting a source into a number of different outputs.
The RB-DA6 has 1 stereo input and 6 stereo outputs. It can also be configured so that 1 mono input can be distributed to 12 outputs by use of a switch which is recessed on the front panel to prevent it being accidentally knocked.
The XLR-3 inputs and outputs are electronically balanced and can be wired unbalanced. Each output is individually buffered so that a short circuit on one output won’t affect the others.
The left and right input gain controls (normalising) are pre-set potentiometers accessible through the front panel.
The output gain may be varied from -8dB to 18dB which is useful for normalising consumer and professional signals to give outputs of -15dBu and 0dBu respectively.
- Audio Specification
- Maximum Input Level +28dBu
- Maximum Output Level +28dBu
- Frequency Response 20Hz to 20kHz +/- 0.1dB (600 ohm load, ref 1kHz)
- Gain Range Adjustable 8dBu loss to 18dBu gain (L & R adjust)
- Common Mode Rejection >66dB typically
- Noise -100dB unity gain, ref +8dBu output
- Distortion 0.01% THD @ 1kHz, ref +8dBu output
- Input Impedance >20kohm bridging
- Output Impedance
