IDX DUO-C198P System Technology 193Wh High-Load Li-Ion V-Mount Battery

The DUO-C198P is the ideal compact battery solution for digital cinema cameras and camera stabilizer systems where long runtimes are required. With its ultra-robust 193Wh capacity and compact 2.4lb design, the DUO-C198P can provide mobile power to cine-style cameras such as the ARRI ALEXA Mini and RED Weapon effortlessly for extended periods at a time. The DUO-C198P also includes two on-battery D-Taps and USB-C outputs to power accessories such as monitors, lights, wireless receivers, tablets, phones and more!

Key Features

  • Features 193Wh capacity
  • The worlds most compact 193Wh Lithium Ion battery (2.4 lbs in weight)
  • Capable of handling up to 14A loads
  • (1) 80W D-Tap Advanced Output (unregulated) – D-Tap Output with the added ability to charge battery using low-cost D-Tap Charger (VL-DT1)
  • (1) 80W D-Tap Output (unregulated)
  • (1) USB-C PD max. input/output 60W (5.0V/3A, 9.0V/3A, 12V/3A, 15V/3A, 20V/3A)(auto shut off after 30 minutes of inactivity)
  • Battery can be charged from USB-C using affordable charger (UC-PD1)
  • 5 Power Indicator LEDs (displaying 10% increments)
  • Battery circuit protection ensures the DUO-C198P is fully protected against common causes of battery misuse, guarding against over charge, over discharge, over current and exposure to high temperatures
  • The highest grade Lithium Ion cells are used to ensure the DUO-C198P is one of the most reliable batteries on the market
  • 11V auto cut-off prevents over-discharging (while load is applied)
  • Fully compatible with all ENDURA V-Mount Battery chargers and accessories
  • Environmentally friendly and recyclable
  • Antiviral and antimicrobial body for peace of mind.
  • The worlds most compact 193Wh Lithium Ion battery (2.4 lbs in weight)
  • (1) 80W D-Tap Output (unregulated)
  • Battery can be charged from USB-C using affordable charger (UC-PD1)
Battery Capacity193Wh (14.54V/ 13.24Ah)
Max.Output Voltage16.8V DC
Nominal Voltage14.54V DC
Maximum Discharge Current14A ‡
D-Tap80W each
USBmax. 60W (5.0V/3A, 9.0V/3A, 12V/3A, 15V/3A, 20V/3A)
End Voltage11V
Battery ProtectionReverse charge, Over charge, Over discharge, Over current, Temperature protection
Ambient TemperatureTo charge: 0°C ~ 40°C (10°C ~ 30°C recommended)
To discharge: -20°C ~ 45°C (10°C ~ 40°C recommended)
To store: -20°C ~ 50°C (one month)
Dimensions97(W)x146(H)x59(D)mm
Weight1090 grams approx.
