E-image GH15 Fluid Video Head

Availability:In stock
Cat No.
8772
SKU
GH15
E-image

Not in stock - Usually delivered in 6-8 weeks

Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. If you require urgent collection and the product is showing in stock , please call us at 01442 292929 or email sales@proav.co.uk to check for availability.

Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. If you require urgent collection and the product is showing in stock , please call us at 01442 292929 or email sales@proav.co.uk to check for availability.

£1,588.80 £1,324.00
- +
Apple Pay
  • Free UK Delivery

    Free UK Delivery

    On orders over £250

  • Price Match

    Price Match

    Request here

Product Information

E-Image GH15 Fluid Video Head

With 15kg(33lbs) capacity, the EIMAGE GH15 Fluid head is a ideal choice for the professional videographers utilizing heavy camcorders who requires the smoothest pan and tilt as well as rapid setup.

It features 9 steps (0-9) counterbalance system with a 2.8" (70mm) sliding plate for perfect balance, and 5 steps of drag plus zero in both pan and tilt.

The head features a built in 1/4"-20 accessory socket for available monitor support arms or other accessory items.

It has self-illuminated Touch Bubbles for easy leveling in poor light conditions. With standard 100mm bowl, the heads could be equipped with all 100mm bowl size legs.

Heavy Duty Fluid Video Head from E-Image
The E-Image Heavy Duty Fluid Video Head from ikan supports cameras and accessories up to 55 pounds, while incorporating a 100mm half ball for quick levelling adjustments. The head features 10 steps of counterbalance, allowing you to adjust the head for operation with lighter cameras. Pan and Tilt drag are individually adjustable and feature levels of 1 to 5, as well as a 0 setting for no drag.

The camera platform accepts a sliding balance plate so you can balance the camera on the head and features a lock and safety release. The head is equipped with two panhandle rosettes, one on each side. It comes with one panhandle, and the head is also equipped with a 1/4"-20 threaded accessory socket for attaching accessories such as support arms. An illuminated bubble level is built into the head so that you can check that your shot is level.

  • Five grades of pan and tilt drag, plus a zero setting, allows you to adjust the head to match the needs of the shot and your operating style. The zero setting removes the drag entirely, allowing the head to move freely.
  • Ten steps of counterbalance, 0 through 9, allows you to fine-tune the head to match the weight of your camera.
  • 100mm half ball tripod fitting provides a wide support platform, making it suitable for use with cameras up to thirty-three pounds. The ball levelling system allows you to level the head independently of the tripod that you choose to mount the head to.
  • It includes a removable panhandle that you can attach to either side of the head. A plastic insert rides between the rosettes on the panhandle and the head, protecting the metal rosettes from contact damage. The rosettes on the head are removable, so if they become damaged they can be replaced.
  • The illuminated bubble level is activated by pressing a small red button on the head, so you can level the head in dim lighting conditions.

Key Features:

  • Supports 33 Pounds
  • 100mm Half Ball
  • Stepped Counterbalance 0 to 9
  • 0 to 5 Grades of Tilt & Pan Drag
  • Sliding Balance Plate
  • L/R Pan Handle Rosettes
  • 1/4"-20 Accessory Socket
  • Illuminated Bubble Level

  • Supports 33 Pounds
  • 100mm Half Ball
  • Stepped Counterbalance 0 to 9

This product includes:

  • 1 x E-Image GH15 Fluid Video Head
  • 1 x Handle for GH15/25 Heavy Duty Fluid Video Heads
  • 1 x GP2 Camera Plate for GH15 / 25 Fluid Video Heads
  • 1 x Tie-Down Knuckle
  • 1 x Plastic Rosette Insert
Payload Range 0-18kg
Net Weight 3.8kg
Counterbalance 0-9
Grades of Pan Drag 0-5
Grades of Tilt Drag 0-5
Tilt Range +90°/-75°
Camera Plate Sliding Plate
Slide Length 145mm
Bowl Size 100mm
Temperature Range -40°/+80°
Pan Bar / Number GB3/1pc
Bubble Level / Illuminated Bubble Level Yes/Yes
