Sony PDW-HR1 XDCAM HD422 Field Station

Sony PDW-HR1 (PDWHR1, HR1) XDCAM HD422 Field Station

The newly developed PDW-HR1 XDCAM HD422 Field Station is a further enhancement to the operational capability of Sony’s XDCAM HD422 series.

The PDW-HR1 packs a large number of functions into its compact yet robust body. With a large 9-inch WVGA LCD, material can be checked on the spot and a wide variety of GUIs offers superb operational efficiency.
The HR1 provides multi-format recording capability as standard, including a frame rate of 23.98P in 1080 mode and SD recording. A wide range of signal interfaces, including baseband video (composite, HD/SD-SDI), Gigabit Ethernet, MPEG TS, DVB-ASI, and HDMI are also provided. What's more, an FTP client capability allows the PDW-HR1 to transfer files via its Ethernet connection without the need for a PC.
Sony PDW-HR1

Key Features

• A large 9-inch WVGA LCD, material can be checked on the spot and a wide variety of GUIs offers superb operational efficiency.
• Multi-format recording capability as standard, including a frame rate of 23.98P in 1080 mode and SD recording.
• A wide range of signal interfaces, including baseband video (composite, HD/SD-SDI), Gigabit Ethernet, optional MPEG TS, DVB-ASI, and HDMI are also provided.
• FTP client capability allows the PDW-HR1 to transfer files via its Ethernet connection without the need for a PC.
• Picture Cache Recording and Disc Exchange Cache.

• large 9-inch WVGA LCD
• Multi-format recording capability as standard

Sony PDW-HR1 Specifications:- General:
Power requirements - AC 100 to 240V, 50/60 Hz, DC +12V, Battery
Power consumption - AC: 65 W, DC: 55 W
Operating temperature - -5 to +45°C (+23 to 113°F)
Storage temperature - -20 to +60°C (-4 to +140°F)
Humidity - 20 to 90% (relative humidity)
Mass - 7.4 kg (16 lb 5 oz)
Dimensions (W x H x D) (excluding protrusions) - 300 x 129 x 400 mm
(11 7/8 x 5 1/8 x 15 3/4 inches)
Recording/Playback format - Video:
MPEG HD422 (CBR: 50 Mb/s)
MPEG HD:
HQ mode (VBR, maximum bit rate: 35 Mb/s)
SP mode (CBR, 25 Mb/s)
LP mode (VBR, maximum bit rate: 18 Mb/s) (Playback only)
MPEG IMX (CBR, 50/40/30 Mb/s)
DVCAM (CBR, 25 Mb/s)

Proxy Video:
MPEG-4

Audio:
MPEG HD422: 8 ch/24 bits/48 kHz
MPEG HD: 4 ch/16 bits/48 kHz
MPEG IMX: 4 ch/24 bits/48 kHz or 8 ch/16 bits/48 kHz
DVCAM: 4 ch/16 bits/48 kHz

Proxy Audio:
A-law (8 ch/8 bits/8 kHz)
Recording/Playback time - MPEG HD422:
50 Mb/s: Approx. 95 min. (PFD50DLA), Approx. 43 min. (PFD23A)

MPEG HD:
35 Mb/s, 4-ch audio: More than 145 min. (PFD50DLA), More than 65 min. (PFD23A)
35 Mb/s, 2-ch audio (playback only): More than 150 min. (PFD50DLA), More than 68 min. (PFD23A)
25 Mb/s, 4-ch audio: Approx. 190 min. (PFD50DLA), Approx. 85 min. (PFD23A)
25 Mb/s, 2-ch audio (playback only): Approx. 200 min. (PFD50DLA), Approx. 90 min. (PFD23A)
18 Mb/s, 4-ch audio (playback only): More than 248 min. (PFD50DLA), More than 112 min. (PFD23A)
18 Mb/s, 2-ch audio (playback only): More than 265 min. (PFD50DLA), More than 122 min. (PFD23A)
MPEG IMX:
50 Mb/s: Approx. 100 min. (PFD50DLA), Approx. 45 min. (PFD23A)
40 Mb/s: Approx. 120 min. (PFD50DLA), Approx. 55 min. (PFD23A)
30 Mb/s: Approx. 150 min. (PFD50DLA), Approx. 68 min. (PFD23A)
DVCAM:
25 Mb/s: Approx. 185 min. (PFD50DLA), Approx. 85 min. (PFD23A)
Search speed range - Jog mode:
-1 to +1 time normal speed

Variable mode:
-1 to +1 times normal speed

Shuttle mode:
-20 to +20 times normal speed

F.Fwd/Rev:
-20/+20 times normal speed
Inputs/Outputs:
Reference input - BNC x 2 (including loop through), HD Tri-level sync (0.6 Vp-p/75 ohms/negative) or SD blackburst/composite sync (0.286 Vp-p/75 ohms/negative)
Analogue composite input - BNC x 1, 1.0 Vp-p/75 ohms/negative, SMPTE 170M
HD-SDI input - BNC x 1
(HD/SD switchable)
HD-SDI: SMPTE 292M (w/embedded audio)
SD-SDI: SMPTE 259M (w/embedded audio)
Analogue audio input - XLR 3-pin (female) x 4 (channel selectable), +4/0/-3/-6 dBu (selectable), 10 k ohms, balanced, CH1 and CH2: switchable phantom powered mic input
Time code input - BNC x 1, SMPTE time code, 0.5 to 18 Vp-p/3.3 k ohms/unbalanced
Analog composite output - BNC x 1, 1.0 Vp-p/75 ohms/negative, SMPTE 170M ,character On/Off
HD-SDI output - BNC x 2,
1: SMPTE 292M (w/embedded audio)
2: SMPTE 292M (w/embedded audio), character On/Off
SD-SDI output - BNC x 1, SMPTE 259M (w/embedded audio), character On/Off
HDMI - x 1, output
Analogue audio output - XLR 3-pin (male) x 42 (channel selectable), +4/0/-3/-6 dBu (selectable), 600 O, Lo-z, balanced, CH3 and CH4: switchable analogue audio monitor
Headphone output - JM-60 Stereo phone jack x 1, -13 dBu, 8 ohms, unbalanced
Time code output - BNC x 1, SMPTE time code, 1.0 Vp-p/75 ohms/unbalanced
i.LINK - IEEE 1394 6-pin x 2*,
1: File Access Mode,
2: (Option: PDBK-202) HDV 1080i/720P IN/OUT

*AV/C (DV) stream is NOT supported.
Ethernet - RJ-45 x 1, 1000Base-T: IEEE802.3ab, 100Base-TX: IEEE802.3u, 10Base-T: IEEE802.3
DVB-ASI output - x 1, (Option: PDBK-202) ISO/IEC-13818-2
Remote (9P) input/output - D-sub 9-pin (female) x 1, RS-422A
DC input (12 V) - XLR 4-pin (male) x 1
DC output (12 V) - 4-pin (female) x 1, DC 12 V, 7.5 W
Maintenance - USB x 2
AC input - x 1, 100 to 240 V, 50/60Hz
Video Performance:
Sampling frequency - Y: 74.25 MHz, Pb/Pr: 37.125MHz
Quantization - 8 bits/sample
Error correction - Reed Solomon Code

Processor Adjustment Range:
Video level - -8 to +3 dB
Chroma level - -8 to +3 dB
Set up/black level - ± 30 IRE/±210 mV
Chroma phase - ± 30°
System sync phase - ± 15 us
System sync phase (fine) - 0 to 400 ns
System SC phase - 0 to 400 ns
Audio Performance:
Sampling frequency - 48 kHz
Quantization - 24 bits
Frequency response - 20 Hz to 20 kHz +0.5/-1.0 dB (0 dB at 1 kHz)
Dynamic range - More than 90 dB
Distortion - Less than 0.05% (at 1 kHz)
Headroom - 20/18/16/12 dB (selectable)
Others:
Built-in display - 9-inch type color LCD monitor
Built-in audio speaker - x 2, L/R
