Product Information
Kramer FC-332 3G HD-SDI to HDMI Format Converter
The Kramer FC-332 is a format converter for HD-SDI signals. The FC-332 unit converts an HD-SDI input with embedded audio to two HDMI outputs.
Key Features:
Input - 1 3G HD-SDI on a BNC connector.
Outputs - 1 3G HD-SDI loop on a BNC connector, 2 HDMI connectors.
HDTV Compatible.
Looping Input.
Multi-Standard Operation - SDI (SMPTE 259M), HD-SDI (SMPTE 292M) and 3G HD-SDI (SMPTE 424M) compliance and support for data rates of 270Mbps, 1483.5Mbps, 1485Mbps and 2970Mbps.
Embedded Audio Group Select Rotary Switch.
Active Input Indication™ Reporting - Green indicates a standard definition (SDI) input signal and blue indicates a high definition (HD-SDI) input signal.
Compact DigiTOOLS™ - 3 units can be rack mounted side-by-side in a 1U rack space with the optional RK-3T rack adapter.
- HDTV Compatible
- Multi-Standard Operation
- Active Input Indicationﾙ Reporting
FC-332 Specs:
Input:
1 SDI, HD-SDI, 3G HD-SDI on a BNC connector
Outputs:
1 SDI, HD-SDI, 3G HD-SDI loop on a BNC connector; 2 HDMI connectors
Max. Data Rate:
Up to 3Gbps
Standard Compliance:
HDMI
Indicator LEDS:
SD/HD, OUT, ON
Power Source:
5V DC, 510mA
Dimensions:
12cm x 7.2cm x 2.4cm (4.7" x 2.8" x 1.0") W, D, H
Weight:
0.3kg (0.7lbs)
Accessories:
Power supply
Options:
RK-3T 19” rack adapter
