Chrosziel Universal Zoom Servo Drive
Availability:In stock
Cat No.
49781
SKU
CDM-UNI-Z2
Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. If you require urgent collection and the product is showing in stock , please call us at 01442 292929 or email sales@proav.co.uk to check for availability.
Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. If you require urgent collection and the product is showing in stock , please call us at 01442 292929 or email sales@proav.co.uk to check for availability.
£2,274.00
£1,895.00
-
Free UK Delivery
On orders over £250
-
Price Match
Request here
Product Information
Chrosziel Universal Zoom Servo Drive
The Zoomer is a compact and universal zoom motor that can be pivoted to almost any lens by simply mounting it on a 15mm rod. The universal motor unit CDM-UNI-Z2 fits seamlessly into the operating functions of the Sony cameras of the FX9 / FX6 / FS7 / FS5 series. The servo drive is controlled via the zoom rocker on the handle. The motor control can be addressed via Sony's camera-specific protocol and also works independently of the camera signals when a LANC zoom rocker is plugged directly into the servo.Due to the included Chrosziel Flexi toothed ring (#206-30), the Zoomer can be used with almost any zoom lens even without toothing.
The multi-function handgrip, which in addition to the recording function and a zoom rocker also provide control over the camera menu and other freely selectable functions, are extremely popular on current video cameras with large sensors and are indispensable for effective operation.The Chrosziel Universal Zoom Servo Drive now allows optimal use of all manual zoom lenses together with the multi-function handgrip. For this purpose, the Zoomer is slid onto a 15mm rod and swiveled onto the zoom lens. Two plug-in cables establish the connection with the camera. One cable is used for the power supply from the camera battery, the second for the connection to the control commands between the handle and the camera.
When using a standard LANC zoom rocker or handle with the Sony PXW-FS5, PXW-FS7 and PXW-FS7II, the servo is connected between the handle and the camera via an input and an output jack to receive all zoom control signals. For setup with the Sony PXW-FX9 camera, a Y-cable is used that accepts the Sony multi-connector and connects to both the input jack of the Zoomer and the input jack of the camera.For the Sony ILME-FX6 camera, a Y-cable is used and connects the 3.5mm connector of the Sony handgrip, input jack of the Universal Zoom Servo Drive, and the Sony camera.
- Universal zoom motor
- Controlled via Sony and LANC handgrip
- Camera control signals forwarded
- 1x CDM-UNI-Z2 Digital motor unit
- 1x LANC cable
- 1x LANC extension cable
- 1x MN-AB-A90 (power supply cable 12 Volt A/B D-Tap – angled 90° rotated 0B 5pin)
- 1x 206-30 Flexi Gear Ring (Ø 60-120mm)
- 1x Gear Drive, mod. 0.8 (Ø 40mm)
- 1x CAB-FX9 for Sony PXW-FX9 compatibility
- 1x CAB-FX6 for Sony PXW-FX6 compatibility
- USB Mini Adapter
| Power supply | 10-30V (Lemo compatible 0B 5-pin) |
| Control command In | 2.5mm socket |
| Control command In&Out | 3.5mm socket |
| USB Type | min A-B (firmware updates) |
| Torque | 0.5Nm |
| Power consumption max | approx. 350mAh @ 12V |
