Fostex 6301NX - 4" Active Monitor Speaker 20W D-Class (Single)
Availability:In stock
Cat No.
49418
SKU
6301NX
Product Information
Fostex 6301NX - 4" Active Monitor Speaker 20W D-Class (Single)
The 6301NX from Fostex is a compact monitor speaker for use in professional mobile, project, or home studios and features a 4" full-range driver powered by an integrated 20W D-class amplifier. Inputs include a transformer balanced XLR connector and a 1/4" unbalanced connector.
The front panel provides a power switch and a rotary level control for easy volume adjustments. An automated protection circuitry prevents overloads and short circuits, while the die-cast aluminum enclosure is made to withstand the rigors of professional use. The 6301NX ships with a standard IEC power cord.
KeyFeatures:
- Compact aluminum design
- 4" full-range driver
- 20W Class-D amplifier for powerful performance
- Transformer balanced XLR input
- 1/4" unbalanced input
- Front-panel rotary volume control
- Protection circuitry keeps the speaker operating smoothly
- Magnetically shielded for safe use near video monitors
- Multi-voltage power supply
- Auto Standby Mode engages after 25 minutes, power consumption reduced to 0.5W
- Optional bracket available separately for mounting
- Compact aluminum design
- 4" full-range driver
- 20W Class-D amplifier for powerful performance
- Transformer balanced XLR input
- 1/4" unbalanced input
- Front-panel rotary volume control
| Type | Sealed powered speaker system |
| Speaker | Cone Type Driver: 4" / 102 mm |
| Amplifier | 20 W Class-D |
| Frequency Range | 70 Hz to 15 kHz |
| Output Sound Pressure Level | 85 dB/W @ 1 m |
| Maximum Output | Maximum SPL: 98 dB |
| Rated Output | 20 W |
| THD | 0.05% (at 1 kHz 1 W output) |
| Input Terminal | Input: 1/4" TS, unbalanced Input: Analog balanced XLR, 3-31 type HOT No. 2 / transformer type |
| Input Impedance | Analog Input: 10 kOhms or More |
| Input Sensitivity | Analog (Unbalanced): -14 dBV (0.2 VRMS) Analog (Balanced): +4 dBu (1.2 VRMS) |
| Residual Noise | −70 dBV |
| Controls | 1 x Power switch 1 x Volume control |
| Indicator LEDs | Unlit: Power off Lit In Green: Power on Lit In Red: In standby |
| Enclosure Material | Aluminum die-casting |
| Shielded | Yes |
| Power Consumption | Power Consumption: 10 W Auto Standby: 0.5 W |
| Dimensions | 7.4 x 4.7 x 4.7" / 189.0 x 120.0 x 120.0 mm |
| Weight | 4.9 lb / 2.2 kg |
| Package Weight | 6.07 lb |
| Box Dimensions (LxWxH) | 9.9 x 9.35 x 7.3" |
