JVC DT-E21L4 21-Inch LCD Monitor

Availability:In stock
Cat No.

Order Now - Usually available to despatch in 7-10 days

£1,794.00 £1,495.00
- +
  • Free UK Delivery

    Free UK Delivery

    On orders over £250

  • Price Match

    Price Match

    Request here

Product Information

JVC DT-E21L4 21-Inch LCD Monitor

JVC's DT-E21L4 monitro is part of their new DT-E Series of HD monitors providing a cost-effective alternative to the industry standard DT-VG1 high-end monitors.

A newly developed TN panel with LED backlights offers improved contrast and black level. The DT-E Series monitors also come complete with free calibration software to help you achieve optimum picture quality. Power consumption on the 17-Inch DT-E21L4 is 20-30% lower compared to CCFL-driven lighting, which also has the effect of increasing the product lifetime by up to 300%. The imaging is also smoother and more consistent with the LED backlighting.

  • Full HD 1920 x 1080 TN Panel
  • TSL protocol compatible and 16CH Audio Level Meter
  • 2 programmable front function keys, where you can select your own function
  • Tally control comes with a new requested feature of split
  • information (dual colour)
  • HD SDI in/out (1.5G)
  • Embedded -Audio Level Meter support of 16ch
  • HDMI input (Screw type)
  • CVBS (BNC) in/out
  • D-sub15 (PC/Component in)
  • Audio x2 (RCA x1,phono x1) in/ x1out
  • RS-232C in , RS-485, make trigger
  • Scale Maker
  • IMD (TSL protocol)
  • Key assign function (2 key with illumination)
  • Integrated speakers
  • Calibration Software
  • Optional: rack mounting
  • Integrated speakers
Display Type21.5 " LCD Display
Apsect Ratio16:9
Pixel number1920 (H) x 1080(V)
Panel surfaceNon-Glare
Viewing AngleH:170deg V:1 60deg
Contrast Ratio1,000:1
Display colour16.7M colours
VESA standard100mm x 100mm (M4 x4)
Width515 mm
Height352.1 mm
Depth181 mm
Weight7.7kg/6.2kg (without stand)
Power RequirementAC: 120, 22 0-24 0V 50/60Hz
DC: 1 2~17V
External In / Out -Video IN/OUT: Composite Vide o IN: BNC x 1
Composite Video OUT: BNC x1 Loop through
Component Analog RGB In: Min i D-Sub 15 pin x 1
HDMI In: HDMI Connector x 1
OUT: BNC x1 (Switched / rec locked out)
Audio: IN: RC A x 2 (L/R) 3.5mm Stereo mini jack x 1
OUT: RCA x 2 (L/R) Monitor Out
Remote: MAKE/TRIGGER: RJ-45 (8 -pin) x 1
RS-485 IN : RJ-4 5 (8 -Pin) x 1
RS-485 OUT : RJ-45 (8-Pin) x 1
RS-232C: D- sub (9-pin) x 1
Audio Speaker Output Power: 1W x 2
