JVC DT-E21L4 21-Inch LCD Monitor
Availability:In stock
Cat No.
8595
SKU
DT-E21L4
Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. If you require urgent collection and the product is showing in stock , please call us at 01442 292929 or email sales@proav.co.uk to check for availability.
Our stock is strategically distributed across multiple warehouses to ensure swift processing and delivery. If you require urgent collection and the product is showing in stock , please call us at 01442 292929 or email sales@proav.co.uk to check for availability.
£1,878.00
£1,565.00
-
Free UK Delivery
On orders over £250
-
Price Match
Request here
Product Information
JVC DT-E21L4 21-Inch LCD Monitor
JVC's DT-E21L4 monitro is part of their new DT-E Series of HD monitors providing a cost-effective alternative to the industry standard DT-VG1 high-end monitors.
A newly developed TN panel with LED backlights offers improved contrast and black level. The DT-E Series monitors also come complete with free calibration software to help you achieve optimum picture quality. Power consumption on the 17-Inch DT-E21L4 is 20-30% lower compared to CCFL-driven lighting, which also has the effect of increasing the product lifetime by up to 300%. The imaging is also smoother and more consistent with the LED backlighting.
- Full HD 1920 x 1080 TN Panel
- TSL protocol compatible and 16CH Audio Level Meter
- 2 programmable front function keys, where you can select your own function
- Tally control comes with a new requested feature of split
- information (dual colour)
- HD SDI in/out (1.5G)
- Embedded -Audio Level Meter support of 16ch
- HDMI input (Screw type)
- CVBS (BNC) in/out
- D-sub15 (PC/Component in)
- Audio x2 (RCA x1,phono x1) in/ x1out
- RS-232C in , RS-485, make trigger
- Scale Maker
- IMD (TSL protocol)
- Key assign function (2 key with illumination)
- Integrated speakers
- Calibration Software
- Optional: rack mounting
- Integrated speakers
| Display Type | 21.5 " LCD Display |
|---|---|
| Apsect Ratio | 16:9 |
| Pixel number | 1920 (H) x 1080(V) |
| Panel surface | Non-Glare |
| Viewing Angle | H:170deg V:1 60deg |
| Contrast Ratio | 1,000:1 |
| Display colour | 16.7M colours |
| Backlight | LED |
| VESA standard | 100mm x 100mm (M4 x4) |
| Width | 515 mm |
| Height | 352.1 mm |
| Depth | 181 mm |
| Weight | 7.7kg/6.2kg (without stand) |
| Power Requirement | AC: 120, 22 0-24 0V 50/60Hz DC: 1 2~17V |
| External In / Out - | Video IN/OUT: Composite Vide o IN: BNC x 1 Composite Video OUT: BNC x1 Loop through Component Analog RGB In: Min i D-Sub 15 pin x 1 HDMI In: HDMI Connector x 1 HD/ SD-SDI: IN: BNC x2 OUT: BNC x1 (Switched / rec locked out) Audio: IN: RC A x 2 (L/R) 3.5mm Stereo mini jack x 1 OUT: RCA x 2 (L/R) Monitor Out Remote: MAKE/TRIGGER: RJ-45 (8 -pin) x 1 RS-485 IN : RJ-4 5 (8 -Pin) x 1 RS-485 OUT : RJ-45 (8-Pin) x 1 RS-232C: D- sub (9-pin) x 1 |
| Audio | Speaker Output Power: 1W x 2 |
